Stabila STBLA180L LA 180 L Multi-Line Laser

Product Overview:

Laying out right angles is a time-consuming job. Moreover, when measurement errors occur high follow-up costs can be the result. The LA 180 L self-levelling multi-line laser allows you to mark out 90° angles, transfer axes and datum lines fast and accurately. The REC 410 Line RF receiver controls the LA 180 L using the STABILA wireless AUTO ALIGNMENT technology. One press of a button and the laser adjusts automatically to the position of the receiver. This laser shows how STABILA answers the construction problems of today.

The Stabila LA 180 L Multi-Line Laser with Auto Alignment function: receiver automatically controls fine alignment of the laser up to 40m. Automatic axis transfer and creation of right angles. Pulsed laser lines for exact height measurements with the receiver (up to 100m) indoors and outdoors. 3 vertical lines, 1 horizontal line and plumb line function.

Product advantages

• Self-levelling multi-line laser for precision results – motorised controller and accuracy of ± 0.07 mm/m.
• AUTO ALIGNMENT function: receiver automatically controls fine alignment of the laser at distances of up to 40 m – fully automatic axis transfer and creation of right angles. Precise alignment without losing the reference point – no measurement errors.
• Pulsed laser lines for exact height measurements with the receiver (up to 100 m) indoors and outdoors.
• Versatile: 3 vertical lines, 1 horizontal line and plumb-line function.
• Extra sharp, easy-to-see lines for fast and efficient work directly on the laser line – measuring range up to 20 m indoors.
• Unique housing shape for positioning in room corners and over edges (e.g. concrete slab) – rapid checking of right angles.
• Shock-absorbing soft grip casing.
• Extensive accessory set: small and large target plates, laser goggles and carrying case.

Application examples

• In metal construction – erecting metal structures in industrial building construction, aligning substructures in façade construction.
• In reinforced concrete construction – transferring axes from batter boards, marking walls on the foundation slab.
• For bricklaying – transferring axes from batter boards, marking walls on the foundation slab, marking partition walls in the basement.
• For carpentry – marking and aligning timber frame walls.
• In drywall construction – transferring layouts from the foundation slab to walls and ceilings, setting up and fixing U-profiles, setting partition walls, hanging ceilings.
• In plumbing and installation work – aligning pipe clips, positioning wires and heating pipes.

Level Accuracy: ± 0.07mm/m
Self-Levelling Range: ± 5.0°
Line Straightness: ±0.1mm/m
90° Angle Precision: ± 0.2mm/m
Laser Beam Accuracy: ± 0.2mm/m
Power: 4 x 1.5V D Cell 1 batteries.
Protection Class: IP54
