Stabila STB106T213 Extendable Spirit Level 3 Vial 17709 213-376cm

Product Overview:

Extremely long and sturdy extendable spirit level that can be adjusted to the required length. The eccentric clamp ensures a high level of accuracy when extended to any position. The upper measuring surface has two small plates to compensate for any irregularities on the surface being levelled. In addition, the two slip-on distance pieces are particularly good for measuring over timber bracing or very uneven surfaces such as bowed timber. Another example of innovative design from STABILA.

Product advantages

• Extendable spirit level with stable 3-chamber aluminium rectangular profile and fixed spacers to even out irregularities on objects.
• Additional slip-on spacers (height: 4.2 cm) for accurate measuring, even over laths.
• Extremely long measuring surface thanks to a unique telescopic system.
• Strong eccentric clamps – for lasting accuracy.
• Finger-grip openings for a secure hold when working.
• Profile with reinforcing ribs for high stability.
• Continuous bridge over the horizontal vial – increases the stability of the profile.
• Plastic end caps protect the profile against impact.
• Telescopic support with a scale in cm/in.
• STABILA installation technology ensures long-term accuracy – measuring accuracy in normal position (retracted) is ± 0.5 mm/m and ± 0.75 mm/m in reverse position (retracted).
•

Equipment: 1 horizontal vial, 2 vertical vials, 2 measuring surfaces, 2 finger-grip openings, telescopic support, slip-on spacers.

Stabila 106T Extendable Spirit Level is extremely strong double-chamber profile has 2 finger holes with the red coated end being telescopic.

The extremely sturdy construction, in conjunction with the strong eccentric clamp, ensures a high level of accuracy when extended to any position.

The printed length scale is ideal for setting the extended length with small plates are provided on one side to even out any irregularities.

A reliable partner when aligning higher and longer constructions, the light metal rectangular profile has 1 horizontal vial and 2 vertical vials.

Measurement Accuracy: in the normal position 0.029° = 0.5 mm/m.

When extended in normal position: 0.057° = 1.0 mm/m. For overhead measurements (in closed position): 0.043° = 0.75 mm/m.
